| IMPA | DN | L | D | C | No of Bolt | h | t | H | D2 |
| 15 | 110 | 80 | 60 | 4 | 12 | 10 | 69 | 35 | |
| 20 | 110 | 85 | 65 | 4 | 12 | 10 | 69 | 37 | |
| 751401 | 25 | 110 | 95 | 75 | 4 | 12 | 10 | 69 | 41 |
| 751402 | 32 | 130 | 115 | 90 | 4 | 15 | 12 | 79 | 41 |
| 751403 | 40 | 140 | 120 | 95 | 4 | 15 | 12 | 93 | 46 |
JIS F 7371 5K Bronze Swing Check Valves: Design Standard: JIS F7371-1996Test Standard: JIS 7400-1996Hydraulic Test Pressure: Corpus-1.05Mpa, Sedes-0.77Mpa～0.4MFlange size as per JIS B2220 - 5K
5.Gasket: non-asbesto
Marine Bronze Swing Check Valve JIS F7371 5K (DN15-DN40)
Categoria:JIS Marine Perscriptio Valvae
Materia:Bronze/Brass
Standards: JIS F7371
Testimonia: CCS, BV, GL, NK, RINA, ABS, DNV, LR
IMPA Code:751401~741403
Ps Price: Latest Price Now
Locus Origin: China
| IMPA | DN | L | D | C | No of Bolt | h | t | H | D2 |
| 15 | 110 | 80 | 60 | 4 | 12 | 10 | 69 | 35 | |
| 20 | 110 | 85 | 65 | 4 | 12 | 10 | 69 | 37 | |
| 751401 | 25 | 110 | 95 | 75 | 4 | 12 | 10 | 69 | 41 |
| 751402 | 32 | 130 | 115 | 90 | 4 | 15 | 12 | 79 | 41 |
| 751403 | 40 | 140 | 120 | 95 | 4 | 15 | 12 | 93 | 46 |
