JIS F 7399 Fuel Oil Tank Emergency Shut-Off ValvesCategory:JIS Marine Velox Clausula ValveMaterial:Bronze, BrassStandards:JIS F7399Certificate:CCS, BV, ABS, DNV/GL, LR, NKPacking Origin Details:Plywood CaseFob Price: Accipe Ultimas Pretium NowPlace :Sina
Locus Origin: China
Sina Marine Bronze Oil Tank Velox Valvae JIS F7399 10K:
Marine Valvae Velox Conclusio adhibetur ad escas olei/lubricatoin oleum pipeline in subitis interclusum. Potest refrenari vecte vel cylindri aeris. Materia mitti potest ferrum, aes, ferrum nodulare.
Operatio type: Manual (Lever) seu Pneumatically operatum
Design Standard: JIS F7399-1996
Test Standard: JIS 7400-1996
Hydraulic Test Pressure: Body- 0.7Mpa, Sedes-0.2Mpa, Sigillum velox clausurae-0.1Mpa
Linge magnitudine ut per JIS B2220 - 10K
Materia principalis:
Corpus: Bronze or Brass
Bonnet: Bronze or Brass
Sedes: Aes vel Brass
Disc: Bronze or Brass
Stem: Brass (C3771BD)
Operatio Spindle: SUS403
Operatio Lever: SUS403
Handwheel: FC200 (Iacta ferrum)
Gasket: non-asbesto
Praecipua Size List (mm):
| DN | d | L | D | C | Bolt Hole NO. | Bolt foramen Diameter | crassitudine LABIUM | H | D2 |
| 10K15 | 15 | 110 | 95 | 70 | 4 | 15 | 12 | 265 | 120 |
| 10K20 | 20 | 120 | 100 | 75 | 4 | 15 | 14 | 265 | 120 |
| 10K25 | 25 | 130 | 125 | 90 | 4 | 19 | 14 | 265 | 120 |
| 10K40 | 40 | 180 | 140 | 105 | 4 | 19 | 16 | 310 | 140 |
| 10K50 | 50 | 220 | 155 | 120 | 4 | 19 | 16 | 335 | 160 |
| 10K65 | 65 | 270 | 175 | 140 | 4 | 19 | 18 | 395 | 180 |
| 10K80 | 80 | 300 | 185 | 150 | 8 | 19 | 18 | 420 | 180 |
