Craneus marinae craneOfflitoris gruis praesertim ad suggestum oleum, suggestum vasis copiam, navigium etc. Fundatur in consideratione API-2C, grues remote agentes possunt esse in conditione laborantis vitae in inboard levare, maiae levare et personas levare.
Grus marina
Marinus grus maxime designatus est ad suggestum oleum, suggestum vasis copia, navigium etc. Fundata consideratione API-2C, grues marinae possunt esse in conditione laborantis vitae inboard levare, outboard levare et personas levare.
Grus instructa esse potest;
Cab aer-condicionibus systematis
Suspensionis brachium proiectura lucernae
Aircraft Obstruction Beacon and Suspension Arm Projection Lamp
Anti- strepitus
Assiduitas contentionis systematis
Electromotor vel pellentesque coegi
Tactus screen propono munus
Mare civitatis munus delectu
Suspenditur homo munus
Testimonia ex CCS, DNV, ABS, GL, LR, BV, RINA, NK, KR aliisque societatibus classificationis.
Praecipua specificatio:
|
Model |
Suboles levato onus radii (t×m) |
Onboard levato onere radii (t×m) |
Levato onus velocitate (t×m.min) |
Flagellum onus radii (t×m/min) |
Luffing tempus(s) |
Celeritas (m / min) |
Potentia (kw) |
|
HO5-15P |
5×15 |
5×15 |
5×30 |
- |
CL:70 |
0.8 |
75 |
|
HO15-10(8.5-18)P |
15×10 8.5×18 |
15×10 8.5×18
|
15×20 |
3×20×30 |
CL:130 |
1 |
160 |
|
HO25-35P |
25×35 |
25×35 |
25×20 |
- |
CL:130 |
0.5 |
315 |
|
HO15-15P |
15×15 |
15×15 |
15×18 3×26 |
- |
RL:100 |
1.5 |
110 |
|
HO16-25P |
16×25 |
16×25 |
16×18 |
- |
RL:100 |
1 |
200 |
|
HO20-16(5-30.5)P |
20×16 5×30.5 |
20×22 7.5×30.5
|
20×10 1×13 |
5×32×30 |
RL:160 |
1 |
224 |
|
HO30-12 (11-30.5) |
30×12 11×30.5 |
30×17 15.5×30.5
|
30×30 |
5×32×70 |
RL:130 |
1 |
315 |
|
HO20-16(5-30.5)P |
20×16 5×30.5 |
20×22 7.5×30.5
|
20×10 1×13 |
5×32×30 |
RL:160 |
1 |
224 |
|
HO30-12 (11-30.5)P |
30×12 11×33.5 |
30×17 15.5×33.5
|
30×30 |
5×32×70 |
RL:130 |
1 |
315 |
|
HO40-102 (11-36.5)P |
40×10 11×36.5 |
40×14 15.5×36.5
|
40×30 |
5×38×70 |
RL:130 |
0.8 |
400 |
|
HO50-15 (15-33.5)P |
50×15 15×33.5 |
50×15 15×33.5
|
50×18 |
10×36×60 |
RL:130 |
0.8 |
350 |
|
HO70-15(30-45)P |
70×15 30×45 |
70×21 40×45
|
70×18 |
20×48×67 |
RL: 180 |
0.85 |
650 |
|
HO80-10(12-45)P |
80×10/12×45(n=4) 40×23/14×45(n=2) |
80×10/12×45(n=4) 40×23/14×45(n=2)
|
80/9(n=4) 40×18(n=2) |
5×47.5×90 |
RL:150 |
0.6 |
336 |
|
Nota: 1. Incessus intentionis: 380V/50Hz ac/3 Ph vel 440V/60Hz ac/3 Ph vel machina pellentesque. 2. Mensa modulus tantum referendi est, requisita specificationes usorum designari possunt. 3. RL funis ferreus luffing, cylindrus CL-oleum luffing. |
Exemplar explicare: HO5-15P 1. HO-Hydraulica Offshore Crane 2. 5-SWL 3.15-Max. radii opus 4. P Offshore basi gruis |
||||||
